SIGLENT
SSU5181A

Mechanical switch, DC~18 GHz, including one SPDT mechanical switch, SMA female.

1435.00
Excl. Vat
Buy
The indicated shipment price may vary according to the number of boxes.

Maximum frequency: 18 / 26.5 / 50 GHz
1 to 4 SPDT switches or 1 to 2 SP6T switch configurations
SCPI controllable via VISA and EasySSU software

USB connectivity
Size (W*H*D): 153 x 62.4 x 137.5 mm
RF connector: SMA female or 2.4mm female

SPDT is a Single Pole, Dual Throw switch where 1 common terminal is switched to 1 of the 2 numbered terminals

SP6T is a Single Pole, 6 Throw switch where 1 common terminal is switched to 1 of the 6 numbered terminals
